Accessory Kits
VT No. OEM
Type
1949-69 Turn Signal Kit, Cotton
1958-84 Turn Signal Kit, PVC
1965-84 Big Twin
Small Starter Wire Set, PVC
32-0163 70165-58 Battery Box to Ground 65-69 BT
32-0323 70018-77 Relay to Solenoid Wire
32-0158 70169-70 Relay to Ground Wire
644
1970-up Wiring Kits feature plas-
tic wire in original factory color
codes, with all terminals applied, in
vinyl loom. Complete “Builders kits"
include handlebar, taillight, coil and
regulator wires, denoted by an *.
All other harnesses are main har-
ness only. Handlebar and taillight
must be purchased separately for these kits. Main harness
include the main turn signal wires.
1970-up PVC Covered Wires
FL-FLH
VT No. OEM
Application
32-0714* 70320-70 1970-72 FLH
32-0715* 70320-73A 1973-77 FLH
32-7569* 70320-78 1978-79 FLH
32-7568* 70320-80 1980-84 FLH
FX-FXE-FXST-FLST
32-7550* 70326-71 1971-72 FXE
32-7551* 70326-73A 1973-74 FXE
32-7584* 70326-75 1975-77 FXE
32-9066 70353-78 1978-79 FXS
32-9074 70343-78 1978-79 FXE
32-8014 70214-80A 1980-85 FXWG
32-8091 69543-80 1980-84 FXS-FXB
32-1118 69545-82A 1982-E84 FXR-FXRS-RT
Early Twins Wiring Harness Kits
feature cotton braided wire and
asphalt loom. Order handlebar and
taillamp wires separately.
VT No. OEM
Application
1916-28 JD Electric Model
32-0700 4735-30 1930-36 VL-RL
32-0701 4735-36 1936-37 WL-UL and FL
32-0703 4735-38A 1938-46 WL-UL-G and FL
32-7555 4736-42M 1942-45 Army 45
32-0704 70320-47 1947 WL-UL-G and FL
32-0705 70320-48 1948-57 UL-EL-FL-FLH & WL
32-0706 7032-58 1958-64 FL-FLH
32-0707 70321-65 1965-69 FLH
Wiring
Wire Plus Z1 Mini Mid Frame System designed from Bobber
and Chopper style bikes with a round oil tank or springs under
the seat with no place to hide anything. This module is supplied
with a billet aluminum cover for visible mounting, holes for view-
ing diagnostic light and measure 1.8" Width x 2"Height x .85"
Deep. Mounts anywhere in the oil tank area.
VT No. Type
32-4156 Mid Frame System with harness for stock style han-
dlebar controls with or without turn signal on auto cancel
32-4157 Mid Frame System with Chopper style harness for
minimal system switches
32-4158 Mid Frame System with harness for stock style han-
dlebar controls. Includes separate 15 amp breaker and wiring
for connection of compression releases
Wire Plus Z1 Standard Mid Frame System has same fea-
tures as Z1 mini but supplied with longer billet cover and
includes lighting control module. Mount both modules in one
compact location.
VT No. Type
32-4159 Mid Frame System with harness for stock style for
stock style handlebar controls
32-4160 Mid Frame System with harness for stock style han-
dlebar controls. Includes separate 15 amp breaker and wiring
for compression releases.
Wire Plus Seat Post Mounted Models features chrome Billet
construction with built in ignition switch. Mounts on seat post
coil bracket on pre 1984 Big Twins and all customs using the
same style coil mount.
VT No. Type
32-6640 Standard
32-6650 Chopper
Early Wiring Components are cloth
covered wire in 25 foot length and har-
ness loom asphalt type in 10 ft length.
Wire
Loom
VT No. Color
VT No. Size
Item
32-8094 Black
3
/
16
" I.D.
Loom
1
/
4
" I.D
Loom
32-8096 Green
3
/
8
" I.D
Loom
32-8097 Yellow
