669
Internal Throttle Parts
Throttle Control Parts listed fit 1936-48, as except noted.
VT No. OEM
Item
49-0150 56271-36 Plunger, Complete Kit, ea
9505-2 3316-31 Plunger only, pair
9804-2 3316-36 31-36 VL, 31-39 45" Plunger Only
49-2005 56245-35 Spiral
49-0956 56276-31 Screw, 10 pk
7626-2 56287-36 Cadmium, pair
7625-2 3330-31 Cadmium, pair
8923-8 9281
Pin
56281-31 Kit for
56278-10 2 Sides
12-1156 9281
Throttle Pin, 4 pk
49-0240 56278-10 Collar
49-2049 56278-10A Collar, Throttle, 1910-72
36-0950 56502-32 Outer
36-0953 56379-09 Wire
49-0156 56283-31 Wire Screw, 10 pk
Throttle Wire End, 1936-48
36-0954 56420-09 Wire End, 10 pk
All Parts Above for Both Sides
Throttle Control Parts 1949-53 All Twins.
VT No. OEM
Item
49-0650 56220-48 Grip Spiral
49-0651 56235-47 Grip Retainer, 2 pk
49-0652 56240-47 Grip Screws, pair
49-0653 56391-49 Plunger, ea
36-0951 56528-49 Outer Control Casing
49-0956 56276-31 Cable Plug Screws, 10 pk
36-0953 56373-09 Inner Wire, each
Above Parts, both sides
Throttle Control Parts, 1954-72 All Twins.
VT No. #
OEM
Item
56220-53 Spiral, Push
56220-58 Spiral, Reverse, Pull
56288-53 Zinc Plug, pair
G
56288-53 Cad Plug, pair
C&D 56278-10 Roller and Pin
9261
Kit
2594
Screw
3207
Screw
56400-53A Plunger
B
56400-53 Plunger
56528-49 Outer Casing
56373-09 Wire
56216-53 Spring
56239-53 Grip End Plug, Zinc, pair
56276-31 Screw, Handlebar Plug
36-0499 Kit includes All Parts Above for Both Sides
Inner and Outer Throttle Spark
Casing Assembly.
VT No. OEM
Years
Type
36-0950 56502-32 1932-48
Outer, Vinyl
36-2579 56502-32 As Above
Cotton braid
1909-31
Outer Nickel Plated
36-0958 3743-09
1909-31
Nut for Above
36-0951 56528-49 1949-53
Outer Vinyl
As Above
Cotton braid
36-0952 56360-54 1954-72
Outer Vinyl
36-0953 56373-09 All, Inner Wire
36-0954 56420-09 Wire End 1909-48
Carb Cable Block attaches inner choke
or throttle cable on Linkert & Bendix
carbs. Includes screws and cotter pin.
VT No. 35-0207
Throttle Spirals and Cable
Kits include all internal parts
for years listed. 1936-48 type
features chrome throttle
sleeves.
Grips not included.
VT No. Years
Sides Throttle Type
36-0498 1936-48 2
Push
36-0497 1949-53 2
Push
36-0499 1954-73 2
Push
36-2551 1954-73 1
Push
36-2574 1954-73 1
Pull
Handlebar Spirals.
VT No. OEM
Years Type
49-0227 3312-16 1916-34 Push
49-2005 56245-35 1935-48 Push, Chrome
1935-48 Push
1936-48 Pull
49-0650 56220-48 1949-53 Push
49-0158 56220-53 1954-70 Push
49-0911* 56220-58 1971-74 Throttle Pull
*Note: Reverses direction on 1954-70 throttle
Handlebar End Nuts.
VT No. Years
Type
9114-2 1910-21 Nickel Plated Hex
7625-2 1931-35 Oxide, Screw
7626-2 1936-48 Oxide, Screw
49-0159 1954-73 Zinc, Screw
9214-2 1954-73 Zinc, Screw as above Colony
