  • 1245


1245
Big Trans Stud Installer
Tool for 1936-86 4 and
5-Speed Softail.
VT No. 16-0719
Transmission Tools For Sportster
VT No. OEM
Year Use
16-0028* 34810
84-90 Mainshaft bearing installer 2pc
16-1755 35820-86 86-90 Gear spacing checker
16-1756 37404-91 91-up Countershaft support plate
16-0139 95560-57 57-84 Door puller
16-1767 37842
91-up 5-Speed bearing installer
*Note: Uses 16-0065 driver
Adjustable Reamers use to fit I.D. on new bushings.
VT No. Years Fits
16-1798 1941-85 BT Main Drive Gear
16-1799 1936-84 BT-XL Kicker Shaft
16-0878 1936-57 BT Brake Cross Shaft
16-1801 1936-84 BT Clutch Release Shaft
Transmission
Shifter Shaft Sleeve Tool use to remove and install the shifter
shaft sleeve in all 5 and 6-speeds. This tool may be used to
remove or install replacement, or upgrade shifter sleeve,
assembly and drum. Use to upgrade to latest shifter assembly
for 5-speeds, 1980-99 Big Twins, and 1980-2000 FLHT, FXR-
FXD. Use to replace shifter sleeve for 5-speeds 2000-up FLHT
& FXD
VT No. Item
Year
Model
16-1664 Tool All
All
10-2489 Bushing 1982-84 FXR
10-2488 Bushing 1985-up FXR-FXD
10-2529 Bushing 1985-99 FLT
10-8752 Bushing 2000-up FLT
Countershaft
Sprocket Lock
Nut Wrench fea-
tures an extra
long two piece
design inner col-
lar which will retain wrench to nut. Fits
1936-up Big Twins, 1 7/8" hex, 4 and 5
speed models.
VT No. OEM
Brand
16-0821 94660-37A V-Twin
16-0757 94660-37A Jims 1/2" Drive
Bushing Tools remove and replace main
drive gear (4th gear) bushings 1936-84 4-
speeds and kicker cover bushings for 1936-
85 4-speed models.
VT No. Item
16-0117 Main Drive Gear
16-0128 Main Drive Gear, Jims
16-1732 Kicker Cover
Big Twin Countershaft Sprocket Nut
Tool is a factory style forged tools.
Includes handle.
VT No. Models Use
16-0114 1937-84 4-Speed BT 4th Gear
Sprocket Nut
Handle for above
16-0823 1941-73 45
Sprocket Nut Tool
Compensating Sprocket Wrench to
install or remove compensating sprockets.
Replaces 94557-55 for 1955-69.
VT No. Item
16-0130 Flat Type
1
/
2
" Drive Type, Jims
