  • 138


138
Chrome Banjo Bolt Kits for use with
universal or stock lines, front and rear,
washers included. The VT No. 37-
8979 is to be used when a master
cylinder or caliper uses a 3/8-24 Banjo
Bolt and the line has a 12mm hole
instead of 10mm.
VT No. OEM
Line
Size/Item
23-0612 41747-82A 10mm
3/8-24
23-0613 41731-82 10mm
Washers
23-0614 41739-84 12mm
7/16-24
23-0615 45583-83 12mm
Washers
37-8979 Special Kit 12mm
3/8-24
14-0568 41731-88 10mm
Washer with O-Ring
14-0567 41733-88 12mm
Washer with O-Ring
Rear Brake Hoses are made of rub-
ber, OE replacements. All hoses are
D.O.T. approved.
VT No. OEM
Years
Model
23-3072 45156-84 1984-86 FXST
23-2290 40956-82 1982-86 FXR
23-3070* 40956-87 1987-94 FXR
23-3069 45156-89C 1990-99 FXST
*Note: Features banjo ends.
Front Steel Brake Tubes are zinc plated. Front fits between
master cylinder and junction. Order rubber hose for final con-
nection to rear cylinder or caliper separately. Fits 1984-E87
FXST and L1984-85 FXWG. Replaces OEM# 45154-84.
VT No. 23-2303
OE Type Brake Lines
Front Brake Hoses are of stock type rubber construction and
D. O. T. approved.
VT No. OEM
Length Fits
23-0742 45112-84A 45" 1984-99 FXST
49" 1984-99 FXST, +4" extended
23-2297 45113-84 46
1
/
2
" 1984-85 FXWG
23-2311 45121-88A 42
1
/
2
" 1984-94 FX-FXE-FXR-FXRS
1986-87 XL 1100
23-2298 45121-88B 42
1
/
4
" As Above
23-2299 45124-84 44
1
/
4
" 1984-85 FXSB
23-2300 45122-84 39" 1984-85 XLX
23-2301 45143-86 38" 1986-99 XL 883
23-2302 42305-86 40" 1986-99 FLST
23-0754 45110-88A 42" 1988-95 FXSTS
Banjo Bolt by Russell accepts brake light
switch and eliminates the need for junc-
tion block. Replaces the standard
3
/
8
x 24
bolt. Sold each.
VT No. 23-0746
10mm Banjo Bolt by Russell features built
in bleeder.
VT No. 23-0616
Brake Banjo Seal Washers feature built in O-Rings.
VT No. OEM
Type
14-0567 41733-88 7/8", 12mm fits handlebar cylinders
1984-00, single disc
14-0568 41731-88 3/8", 10mm fits 1982-00 Dual Disc
Brake Calipers
14-0578 41731-01 Fits 2001-up Master Cylinder &
Brake Calipers
Allen Button Head Banjo Bolts sold without
washers.
VT No. Size
MM
8517">37-8517 3/8-24 10
8518">37-8518 7/16-24 12
Chrome Banjo Bolts include seal washers.
VT No. Size
MM Style
2190-3 3/8 x 24 10
Dome
2191-3 3/8 x 24 10
Allen
2192-3 7/16 x 24 12
Dome
2193-3 7/16 x 24 12
Allen
23-0882 2004-up XL 10
Hex
23-0883 2004-up XL 12
Hex
Banjo Bolts
